 CA DIE

Special Dies – CA, Ogival, Radius Point, P-Point, Hilo, Hilo gimlet, Annular ring, Hoseclamp, Swageform, Align-rite, NPTF, Lock Thread, Annular Fetter, Ulma design

COMBINATION DIE (THREAD & KNURL)

Combination Dies Threading & Knurling simultaneously
Form & Groove Rolling, Combination dies (thread & point, thread & knurl, thread & groove), Chamfer dies
Knurl (straight, diagonal, male diamond, female diamond), knurl with cut-outs

GIMLET DIE

Woodscrew, Sheet Metal thread forming screws (ANSI àAB, A, B, DIN, JIS, TAV, UNI), Chipboard, Lag screw with gimlet, cone, blunt, fade, radius points
Thread cutting screws (F, BF, Paintscraper, CY, YB, VA)
Other thread screws (U, wood drive screw, screw nails)

MATPOINT DIE & REMINC, REED SPECIALS

MATHREAD® (MAThread®, MATPoint®)
REMINC® (Taptite 2000®, Taptite II®, Taptite®, Duo-Taptite®, Fastite 2000®, Plastite®, Powerlok®, Extrudetite® Cut-Off & Non Cut-Off, Taptite CA®, )
REED (HPTS, HPTRS Design)
REED (F3® Design for various thread forming & thread cutting screws)

SPIRAL FORM DIE


WSH Spiralform® (also with gimlet point)

PT DIE


EJOT® (PT®, Delta PT®, Duro PT®, DG PT®, with gimlet & radius point)

FLAT GROUND (BOLTMAKER)


Boltmaker, Californian Boltmaker
Boltmaker (Single, Split face, with cut-outs)
All machine screw threads (ISO, Unified, Whitworth, MJ, and UNJ). These are Ground Thread Dies.

FLAT GROUND (DUPLEX)

HLT - Duplex –C3, C6, L3
Reed Design ( STD. Duplex
All machine screw threads (ISO, Unified, Whitworth, MJ, and UNJ). These are Ground Thread Dies.
